Front Panel Components
Figure 1-1 Front panel components
(1) Secure USB compartment (4) Line-out (headphone) audio connector
(2) Power button (5) Line-in (microphone) connector
(3) Flash activity LED (6) Universal serial bus (USB) connectors (2)
For more information, refer to the model-specific QuickSpecs at http://h18004.www1.hp.com/products/quickspecs/
QuickSpecs_Archives/QuickSpecs_Archives.html.
ENWW Front Panel Components 3
