Memory Configurations
Flash Memory
Memory Slot 1
(DDR-3)
Memory Slot 2
(DDR-3)
2 GB 1 GB
Empty
2 GB 2 GB
Empty
4 GB 2 GB
Empty
Processor
Intel Atom N280 1.66 GHz
Memory
Flash Memory
Up to 4 GB (for boot drive)
System Memory
Up to 2 GB DDR-3 SODIMM in standard configurations (up to 8 GB supported)
NOTE:
64 MB minimum reserved for graphics memory (Intel GL40 chipset
dynamically allocates graphics memory)
Graphics
Intel GL40 graphics with support for two high-resolution monitors up to 2048 x 1536, or up to 32 bit color
depth
*
Mode
Color depth
Refresh rate
640 x 480
8/16/32bit
60, 70, 75, 85
800 x 600
8/16/32bit
60, 75, 85
1024 x 768
8/16/32bit
60, 70, 75, 85
1280 x 720
8/16/32bit
60, 75, 85
1280 x 768
8/16/32bit
60, 75, 85
1280 x 1024
8/16/32bit
60, 75, 85
1400 x 1050
8/16/32bit
60, 75, 85
1440 x 900
8/16/32bit
60, 75, 85
1600 x 1200
8/16/32bit
60, 75 ,85
1680 x 1050
8/16/32bit
60
1920 x 1080
8/16/32bit
60, 75, 85
1920 x 1200
8/16/32bit
60, 75
2048 x 1536
8/16/32bit
60
NOTE:
This table represents a sample of possible modes that this controller is capable of displaying but
various factors such as the capability and EDID info returned by the attached monitor, the interface used
(D-SUB/DisplayPort or optional DVI-D with dongle), and dual monitor mode may limit the availability of
modes, color depth, and/or refresh rate.
Input/Output/
Peripheral Support
Keyboard
USB or PS/2 (varies by region)
Mouse
USB or PS/2 (varies by region)
Printer
Local and/or network printers (RDP, ICA, LPD)
Video
Intel GL40 graphics
Audio
Output
Internal amplified speaker, 1/8-inch mini, full 16-bit stereo, 44-kHz sample
rate.
Input
1/8-inch mini microphone
Hardware Security
Security lock slot (cable lock sold separately)
Secure USB compartment with 2 USB 2.0 ports
Networking
10/100/1000 Gigabit Ethernet (RJ-45)
QuickSpecs
HP t5740 Thin Client
Technical Specifications
DA - 13496 North America — Version 15 — February 21, 2013
Page 9
