HP TouchSmart IQ500 - Desktop PC

4 Upgrading and Servicing Guide
5 Remove the connector cover by inserting your finger under the gap on the bottom-left side of the
cover (A), and then pulling gently.
6 Disconnect all other attached cables from the back of the HP TouchSmart PC.
A
