Chapter 1 15
Introduction
Installing the Hardware
B180 Graphics Slots
Supported B180 Configurations:
• 1 built-in Visualize EG and Visualize fxe
• 1 built-in Visualize EG and Visualize fx2
• 1 built-in Visualize EG and Visualize fx4
B1000 and C3000 Graphics Slots
Use the Primary Graphics Slot for the highest performance graphics card. Use the
Secondary Graphics Slot for the second graphics card and then the remaining 64 bit
wide slots for any additional supported graphics cards.
PCI slot 1 32 bits wide/33Mhz
PCI slot 2 32 bits wide/33Mhz
PCI slot 1 64 bits wide/33Mhz
PCI slot 2 64 bits wide/66Mhz - Primary Graphics Slot
PCI slot 3 64 bits wide/33 Mhz
PCI slot 4 64 bits wide/33Mhz - Secondary Graphics Slot
PCI slot 5 32 bits wide/33Mhz
PCI slot 6 32 bits wide/33Mhz
