16 Chapter1
Introduction
Installing the Hardware
Supported B1000 and C3000 Graphics Configurations:
• 4 Visualize EG cards or
• 4 Visualize fxe or
• 1 Visualize fx2 or
• 1 Visualize fx4 with texture Mapping
B2000 Graphics Slots
Use the Secondary Graphics Slot for the highest performance graphics card. Use the
Tertiary Graphics Slot for the second graphics card and then any of the remaining 32
bit slots for the third PCI graphics card.
Supported B2000 Graphics Configurations:
• 3 Visualize fxe and built-in Visualize fxe
• 1 Visualize fx4 with Texture Mapping and built-in Visualize fxe
PCI slot 1 64 bits wide/33Mhz - Secondary Graphics Slot
PCI slot 2 64 bits wide/33Mhz - Tertiary Graphics Slot
PCI slot 3 32 bits wide/33Mhz
PCI slot 4 32bits wide/33MHz
