HP w2007 Servise Manual

20" LCD Color Monitor HP W2007&W2007v
24
7.3 Key Board
CN001
CONN
1
2
3
4
5
C0060.1uF 50V
LBADC1
C002
0.001uF
(3K)
C0040.1uF 50V
C001
0.001uF
DOWN
T98SMMN8WRHPDC 2
HP w1907/W2007 A
22Thursday , July 24, 2008
715G3125-2
.
02 OSD KEY
G3125-2-X-X-1-080719
OEM MOD EL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
备注
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
线路图编号
R001 3K 1/10W 5%
MENU
UP
SW001
SW
(DOWN)
R003 3K 1/10W 5%
OK
R004 1K8 1/10W 5%
CONNECTOR
RJ001 0R05 1/8W
DOWN
GND
R002 1K8 1/10W 5%
(UP)
OK
LBADC1
C0030.1uF 50V
SW004
SW
UP
(3K)
GND
(1.8K)
C0050.1uF 50V
SW003
SW
(MENU)
LBADC2
(1.8K)
(OK)
LBADC2
MENU
SW002
SW

HP w2007 Specifications

General

Resolution	1680 x 1050
Aspect Ratio	16:10
Contrast Ratio	1000:1
Brightness	300 cd/m²
Response Time	5 ms
Dynamic Contrast Ratio	3000:1
Panel Type	TN
Viewing Angle	160° horizontal, 160° vertical
Display Size	20 inches
Inputs	VGA
Power Consumption	45W (operational), <2W (standby)
