HP w2007 Servise Manual

20" LCD Color Monitor HP W2007&W2007v
52
D105 093G 64 42 P BAV70 SOT23 BY PAN JIT
ZD103 093G 39GA01 T RLZ5.6B
ZD102 093G 39GA01 T RLZ5.6B
ZD101 093G 39GA01 T RLZ5.6B
D106 093G 39GA01 T RLZ5.6B
D107 093G 39GA01 T RLZ5.6B
D108 093G 39GA01 T RLZ5.6B
D109 093G 39GA01 T RLZ5.6B
ZD104 093G 39GA01 T RLZ5.6B
ZD105 093G 39GA01 T RLZ5.6B
ZD106 093G 39GA01 T RLZ5.6B
715G2559 3 3 MAIN PCB FR-4 1.6MM D/S
KEPC8QHP3 KEY BOARD
CN004 033G8032 4F HR CONNECTOR
SW005 077G 607 1 FD TACT SWITCH
LED001 081G 14 20 AV LED AQUA WHITE / AMBER
715G3126 1 FR-4 T0.8mm 48.6*16MM
CN004 033G8032 4F U CONNECTOR
KEPC8QHP4 KEY G3125-D-LN-X-1-080411
CN001 033G3802 3 BH F WAFER
SW003 077G 603 2 CJ TACT SWITCH
SW002 077G 603 2 CJ TACT SWITCH
SW001 077G 603 2 CJ TACT SWITCH
SW004 077G 603 2 CJ TACT SWITCH
SW003 077G 603 2 HJ TACT SWITCH
SW004 077G 603 2 HJ TACT SWITCH
SW001 077G 603 2 HJ TACT SWITCH
SW002 077G 603 2 HJ TACT SWITCH
R002 061G0603182 RST CHIPR 1.8 KOHM +-5% 1/10W
R004 061G0603182 RST CHIPR 1.8 KOHM +-5% 1/10W
R001 061G0603302 RST CHIPR 3 KOHM +-5% 1/10W
R003 061G0603302 RST CHIPR 3 KOHM +-5% 1/10W
RJ001 061G0805000 RST CHIPR 0 OHM +-5% 1/8W
C002 065G0603102 32 1000PF +-10% 50V X7R
C001 065G0603102 32 1000PF +-10% 50V X7R
C003 065G0603104 32 CHIP 0.1UF 50V X7R
C004 065G0603104 32 CHIP 0.1UF 50V X7R
C005 065G0603104 32 CHIP 0.1UF 50V X7R
C006 065G0603104 32 CHIP 0.1UF 50V X7R
715G3125 2 KEY PCB FR-1 S/S T:1.6MM 83.2X11MM

HP w2007 Specifications

General

Resolution	1680 x 1050
Aspect Ratio	16:10
Contrast Ratio	1000:1
Brightness	300 cd/m²
Response Time	5 ms
Dynamic Contrast Ratio	3000:1
Panel Type	TN
Viewing Angle	160° horizontal, 160° vertical
Display Size	20 inches
Inputs	VGA
Power Consumption	45W (operational), <2W (standby)
