Installing an HDD in an HP 400 Workstation
To install an HDD:
1. Follow the procedures described in
Preparing for component installation on page 39 to prepare the
workstation for component installation.
2. Select a drive bay in which to install the hard disk drive.
3. Locate the four isolation grommet screws on the chassis.
4. Install the four isolation grommet screws as shown in the following figure.
Figure 9-1 Installing the grommet screws
50 Chapter 9 Installing hard disk drives ENWW
