HP 2-button Optical
Scroll Mouse
(USB)
Dimensions
(H x L x W)
1.5 x 4.5 x 2.5 inches; 3.8 x 11.6 x 6.3 cm
Weight
0.27 lb (0.12 kg)
Cable length
72.8 inches; 185 cm
System requirements
Microsoft Windows Vista Business 32 or 64, Microsoft Windows XP
Professional, Microsoft Windows XP Professional x64 Edition, Red Hat
Enterprise Linux Workstation 3 and 4
HP Optical 3-Button
Mouse
(USB)
Dimensions/Weight
Height
1.5 inches; 3.76 cm
Length
4.5 inches; 11.56 cm
Width
2.4 inches; 6.19 cm
Weight
3.80 oz (108 g)
Environmental
Operating temperature
32° to 104° F (0° to 40° C)
Non-operating
temperature
-4° to 140° F (-20° to 60° C)
Operating humidity
10% to 90% (non condensing at ambient)
Mechanical
Tracking speed
6 in/s Maximum
Switch life
3,000,000 operations
Switch type
Micro-switches
Tracking mechanism
life
155 miles (250 km) at average speed of 10
in/s
Cable length
9.5 ft (2.9 m)
System requirements
Microsoft Windows Vista Business 32 or 64,
Microsoft Windows XP Professional, Microsoft
Windows XP Professional x64 Edition, Red
Hat Enterprise Linux Workstation 3 and 4
HP SpacePilot 3D USB
Intelligent Controller
(model EF390AA)
Physical
Characteristics
Dimensions
(L x W x H)
9.3 x 5.6 x 2.0 inches; 236 x 143 x 53 mm
Weight
1.875 lb (0.85 kg)
Palmrest
Sculpted
Mechanical
Buttons
21+ programmable speed keys
15 reprogrammable
LCD Viewing Area
(W x H) 4.1 x 1.2 inches; 102 x 30 mm
Active Area
(W x H) 3.9 x 1.0 inches; 98 x 26 mm
Display Format
240 x 64
Motion Controller
Six degrees of freedom motion control
through the X, Y, Z axis (pitch, roll, yaw)
Device Sensitivity
Adjustable to preference
System Requirements
Intel Pentium 4 or AMD Athlon processor based system
20 megabytes free disk space for driver and plug-in installation (CD-
ROM device required)
USB 1.1 or 2.0
Operating System
Supported
Microsoft Windows 2000 and XP
QuickSpecs
HP xw6400 Workstation
Technical Specifications - Input/Output Devices
DA - 12505 Worldwide — Version 21 — August 16, 2007
Page 54
