HP L1965 Flat Panel
Monitor
Panel
Type
Active matrix, thin film transistor (TFT)
Viewable Image Area
(diagonal)
19 inches; 48.25 cm maximum viewable
Screen Opening
(WxH)
14.9 x 12.0 inches; 38.0 x 30.5 cm
Viewing Angle
(typical)
178 degrees horizontal/178 degrees vertical
(10:1 minimum contrast ratio)
Brightness
(typical)
300 nits (cd/m2)
Contrast Ratio
(typical)
1000:1 (typical)
Response Rate
(typical)
6 ms (typical gray to gray)**
Pixel Pitch
0.294 mm
Backlight Lamp Life
(to half brightness)
50K hours
* All performance specifications represent the typical specifications
provided by HP's component manufacturers; actual performance may
vary either higher or lower.
** 20 ms rise and fall
Video/Other Inputs
Plug and Play
Yes (supports VESA DDC2B and DDC/CI;
PC2001 compliant)
Self Powered USB 2.0
Hub
One upstream, four downstream ports (cable
included)
Input Signal
Two DVI-I connectors (VGA analog or digital)
Input Impedance
75 ohms ± 2%
Sync Input
Separate sync (HSYNC/VSYNC); composite
sync, Sync on Green (activated through on-
screen display)
Video Cable
One DVI-D to DVI-D, and 1 DVI-I to VGA
cables
Video Cable Length
71 in (1.8 m)
Signal Interface/
Performance
Horizontal Frequency
24 to 83 kHz
Vertical Frequency
48 to 76 Hz
Native Resolution
1280 x 1024 @ 75 Hz analog
1280 x 1024 @ 60 Hz digital
Maximum Resolution
(Analog)
1280 x 1024 @ 75 Hz analog
Maximum Resolution
(Digital)
1280 x 1024 @ 75 Hz digital
Preset VESA Graphic
Modes
(non-interlaced)
640 x 480 @ 60 Hz, 72 Hz, 75 Hz
720 x 400 @ 70 Hz
800 x 600 @ 60 Hz, 72 Hz, 75 Hz
1024 x 768 @ 60 Hz, 70 Hz, 75 Hz
1280 x 1024 @ 60 Hz, 75 Hz
Preset MAC Mode
832 x 624 @ 75 Hz
1152 x 870 @75 Hz
Preset VGA Mode
640 x 480 @ 60 Hz, 72 Hz
Preset SUN Mode
1152 x 900 @ 76 Hz
QuickSpecs
HP xw6400 Workstation
Technical Specifications - Monitors
DA - 12505 Worldwide — Version 21 — August 16, 2007
Page 77
