Power
Source
Four-pin, DC power receptacle
DC Power Requirement
5 VDC ± 5% – 100 mV ripple p-p
12 VDC ± 5% – 200 mV ripple p-p
DC Current
5 VDC – <800 mA typical,
< 1000 mA maximum
12 VDC – < 870 mA typical,
<1800 mA maximum
Audio Output
Line-Out
0.7 VRMS
Signal-to-Noise Ratio
85 dB
Channel Separation
65 dB
Configuration Jumper
Block
Master, slave, and cable select modes
Data Interface
Connector
40-pin, shrouded and keyed, flat ribbon
Operating
Environmental
(all conditions non-
condensing)
Temperature
(operating)
41° to 122° F (5° to 50° C)
Relative Humidity
(operating)
10% to 85%
Maximum Wet Bulb
Temperature
(operating)
86° F (30° C)
Certifications,
Approvals
MMC II support, multi-read certification, Microsoft WHQL certification,
ACA AS/NZS 3548 class B, CNS 13438, C.I.S.P.R. Pub 22, TUV or
VDE EN60950, EN 55022, EN55024, EMKO EN60950, EN 60825-1, UL
60950, CSA C22.2 60950-2000, CFR 21 part 1040 class 1, CFR 47
C.I.S.P.R. Pub 22 Class B, DHHS/FDA, ANSI C63.4-1992
Operating Systems
Supported
Microsoft Windows 2000, Windows XP Professional
Kit Contents
16X/48X DVD-ROM Drive, InterVideo WinDVD MPEG Movie Playback
software, audio cable, and installation guide.
HP 48X CD-RW/DVD-
ROM Combo Drive
Form Factor
5.25", half-height, tray-load
Mounting Orientation
Horizontal or vertical
Interface
ATAPI/EIDE
Dimensions
(HxWxD)
5.77 x 1.71 x 7.87 [max] inches; 14.66 x 4.34 x 20.0 [max] cm (external,
excluding bezel)
Weight
(max)
2.6 lb (1.2 kg)
QuickSpecs
HP xw6400 Workstation
Technical Specifications - Optical Devices
DA - 12505 Worldwide — Version 21 — August 16, 2007
Page 58
