Front I/O
2 USB 2.0, Headphone, Microphone, optional IEEE 1394
NOTE:
Although HP Personal Workstations can be ordered with the HP Installer Kit for Linux and
an IEEE 1394 card, HP cannot provide customer support for this configuration. Please refer to the
Linux Hardware Support Matrix (
http://www.hp.com/support/linux_hardware_matrix
) for details, and
to the Linux User Manual (
http://www.hp.com/support/linux_user_manual
) for tips on user-
enablement of the IEEE 1394 Card.
Internal I/O
1 USB 2.0 header
Rear I/O
5 USB 2.0, 1 standard serial port, 1 parallel port, PS/2 keyboard and mouse, 1 RJ-45 to integrated
Gigabit LAN, Audio In, Audio Out, Microphone In
Choice of PS/2 or USB
Keyboard
1
Choice of PS/2 or USB
Mouse
1
Chassis Dimensions
(H x W x D)
17.3 x 6.5 X 17.3 inches; 44.1 x 16.5 x 44.0 cm
System Weight
Minimum config – 14.60 kg (32.30 lbs)
Maximum config – 18.11 kg (39.94 lbs)
Temperature
Operating
40° to 95° F (5° to 35° C)
Non-operating
-40° to 140° F (-40° to 60° C)
Humidity
Operating
8% to 85%
Non-operating
8% to 90%
Maximum Altitude
(nonpressurized)
Operating
10,000 ft (3,000 m)
Non-operating
30,000 ft (9,100 m)
Power Supply
575W wide-ranging, active Power Factor Correction
Interfaces Supported
4-channel SATA interface (4 Serial-ATA connectors each), 2 EIDE interface (2 EIDE connectors)
supported for optical drives, USB 2.0, IEEE 1394 (optional)
Hard Drive Controller
Supported
SATA (integrated) or optional SAS (PCIe) controllers
QuickSpecs
HP xw6400 Workstation
Standard Features - Specs
DA - 12505 Worldwide — Version 21 — August 16, 2007
Page 9
