HP xw6400 Mini White Paper

Benchmarks
The charts below compare the performance of the File Server workload and Workstation workload
using the IOMeter test harness. The charts show the performance improvement of a 4 disk RAID 0
configuration over a single disk configuration.
Worksation Workload RAID 0 Performance
0.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
SATA 10K NCQ SAS 10K SAS 15K
Relative Performance
Single Disk
4 Disk RAID 0
Chart 1 Workstation Workload RAID 0 Performance
File Server Workload RAID 0 Performance
0.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
SATA 10K NCQ SAS 10K SAS 15K
Relative Performance
Single Disk
4 Disk RAID 0
Chart 2 File Server Workload RAID 0 Performance
Results
As shown in the first chart, the 4 disk RAID 0 array has a clear performance advantage for the
Workstation workload – almost 3x as fast for SATA disks, almost 5x the performance of the 10K SAS
disk, and almost 8x as fast as the SAS 15K disk. A similar result is seen for the File Server Workload.
For those who need the best performance, regardless of cost, a RAID 0 configuration of SAS 15K
disks can be a great choice. The 10K SATA Drives are also relatively fast and represent an excellent
price/performance tradeoff, as the SAS drives are relatively expensive.
3

HP xw6400 Specifications

General

Chipset	Intel 5000X
Storage	SATA or SAS hard drives
Power Supply	650W
Memory	Up to 16 GB DDR2
Expansion Slots	2 PCIe x16
Network	Integrated Gigabit Ethernet
Operating System	Windows XP Professional
Graphics	NVIDIA Quadro FX series
