3.2 Workstation Disassembly Procedures
1. Remove/disengage any security devices that prohibit opening the workstation.
2. Disconnect the power cord from the electrical outlet and then from the workstation.
3. Disconnect all peripheral device cables from the workstation.
4.
Remove the access panel. Pull up on the handle 1 and lift off the cover 2.
5. Disconnect all internal cables from system board, power supply, and other components.
EL-MF877-00 Page 3
Template Revision A 438710-001
