HP Z800 Configuration Guidelines

Page 2 of 24 Joe Conforti – Avid Technology – October 27th, 2011
Rev A
2.) Qualified Operating Systems for Avid Client Editing Applications, Hardware and Shared-Storage
connectivity for the HP Z800 with Media Composer / Symphony 6.0 , NewsCutter 10 or later:
- Supported: Only Microsoft® Windows 7 Professional 64-bit Edition with SP1 (SP1 required)
- Not Supported - Microsoft® Windows XP 32-bit, 64-bit (any version)
- Not Supported - Microsoft® Windows Vista 32-bit, 64-bit (any version)
- Not Supported - Microsoft® Windows 7 – any 32-bit version, or any version of Home, Ultimate or
Enterprise editions.
Note regarding Service packs:
As of this writing Service Pack 1 is the current Service Pack release for Win7. SP1 is required for Media
Composer 6.0, Symphony 6.0 and NewsCutter 10. As future Service Packs are released Avid will evaluate
and announce formal support when testing is completed.
3.) Qualified Hardware and shared storage supported:
AVID qualified Hardware / Shared Storage
Qualified / Supported
Mojo DX
Yes
Nitris DX
Yes
3
rd
Party Qualified Hardware
See release notes and Avid website for
information regarding supported 3
rd
party
hardware (vendor qualified)
Unity ISIS System Infrastructure
ISIS 1.4 Infrastructure
Unity ISIS 1 Gbit Ethernet Client
ISIS 2.03 Client
Unity ISIS Hi-res (10 Gbit) client
Requires minimum ISIS 2.2
ISIS 7000 only
Unity MediaNet Infrastructure
MediaNet 4.2.4 Infrastructure
Unity MediaNet Fibre
MediaNet 5.1.2 Client
Unity MediaNet AECIFs
MediaNet 5.1.2 Client
1394 Adrenaline DNA
N/A Not Supported
1394 Mojo-SDI DNA
N/A Not Supported
1394 Mojo-Analog DNA
N/A Not Supported

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
