HP Z800 Configuration Guidelines

Page 3 of 24 Joe Conforti – Avid Technology – October 27th, 2011
Rev A
AVID qualified HBA info
AVID qualified HBA AVID Part Number Slot
Location
Function
Avid HIB, DX Interface HBA**
Active: 7030-30048-01
Active: 7030-20084-01
Passive: 7030-30021-01
#1
Avid DX Hardware Interface HBA
Qualified 3
rd
party hardware
interface (vendor qualified)
Not stocked by AVID #1
See release notes and Avid website for
information regarding supported 3
rd
party
hardware
Atto FC-41ES 7030-20004-01 #4 Shared Storage: Unity MediaNet Fibre
Intel PRO 1000 PT - ISIS 7030-20139-01 #4 Shared Storage: Unity ISIS Copper Gb-Ethernet
Intel PRO 1000 PF - ISIS Not stocked by AVID #4 Shared Storage: Unity ISIS Optical Gb-Ethernet
Myricom 10G-PCIE-8B-S
Requires minimum ISIS 2.2
(ISIS 7000 only)
7030-30041-01 #4 Shared Storage: Unity ISIS 10Gb-Ethernet
Requires minimum ISIS 2.2 (ISIS 7000 only)
Atto R380 7030-20166-01 #5 Local SAS Storage Support –
Avid VideoRAID ST (5-bay)
Xtore StudioRAID 5Ti (5-bay)
Atto UL5D 7030-20002-01 #5
Local u320 SCSI Storage – VideoRAID RTR &
Legacy Avid u320 SCSI storage
(The UL5D BIOS should be disabled)
**
Avid DX Interface HBA Support Note: (See reference pictures on page 6 of this guide).
All 3 versions of the DX interface HBA are supported with the Media Composer / Symphony 6.x and NewsCutter 10.x
1) Active DX interface HBA 7030-30048-01
2) Active DX interface HBA 7030-20084-01
3) Passive DX interface HBA 7030-30021-01

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
