HP Z800 Configuration Guidelines

Page 4 of 24 Joe Conforti – Avid Technology – October 27th, 2011
Rev A
4.) Slot Configuration:
Slot Configuration Information
Slot # Electrical Mechanical
1 x4 PCI-E Gen 2 x8
Avid HIB, DX Interface HBA
Active: 7030-30048-01 & 7030-20084-01
Passive: 7030-30021-01
OR
Vendor Qualified 3
rd
Party Hardware PCI-e Interface
See release notes and Avid website for information regarding
supported 3
rd
party hardware
2 x16 PCI-E Gen 2
(225Watts)
x16 Graphics Card:
Quadro 4000
**
Quadro FX 3800
**
Quadro FX 4800
***
3 x4 PCI-E Gen 1 x8
Not Used
4 x8 PCI-E Gen 2 x16 Shared Storage Controllers:
Atto FC-41ES – MediaNet LAN Share
Intel PRO 1000 PT – ISIS 5000 / 7000
Intel PRO 1000 PF – ISIS 5000 / 7000
Myricom
10G-PCIE-8B-S – ISIS 5000 / 7000
5 x16 PCI-E Gen 2
(225Watts)
x16 Local Storage Controllers:
Atto R380 – SAS Avid VideoRAID ST (5-bay) support
Atto R380 – SAS Xtore StudioRAID 5Ti (5-bay) support
Atto UL5D - Legacy u320 SCSI support
(The UL5D BIOS should be disabled)
6 PCI-E 32bit /33MHz PCI 32/33
Secondary SAS Port (Embedded)
7 x8 PCI-E Gen 2 x16
Optional if needed –
Panasonic P2 PCI-E reader HBA, USB 3.0 HBA
Embedded Broadcom
BCM5764 GbE NIC
PCI-E x1
Gen 1
Not qualified for Avid ISIS 5000 / 7000 Connectivity
Qualified for Avid MediaNetwork AECIFs
** qualified only with 6-core X5650 2.66 GHz processors
*** qualified only with 4-core X5570 2.93 GHz and 4-core X5550 2.66 GHz processors

HP Z800 Specifications

General

Processor cache	8 MB
Processor model	E5560
Processor frequency	2.8 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Number of processors installed	2
Audio system	Integrated High Definition Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Product type	Workstation
Motherboard chipset	Intel® 5520
ECC	Yes
Maximum internal memory	192 GB
HDD speed	15000 RPM
HDD capacity	446 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD Super Multi
Card reader integrated	No
I/O ports	Front: 3 USB 2.0, 1 IEEE 1394a, 1 microphone in, 1 headphone out; Rear: 6 USB 2.0, 1 IEEE 1394a, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 2 RJ-45 to integrated Gigabit LAN, 1 serial; Internal: 3 USB 2.0
Headphone outputs	1
USB 2.0 ports quantity	9
Parallel ports quantity	0
Power supply	1110 W
Power consumption (typical)	240 W
Non-operating altitude	9100 m
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 90 %
Operating relative humidity (H-H)	8 - 85 %
Display	HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch widescreen), HP LP3065 30-inch Widescreen LCD Monitor (all sold separately)
Drive bays	3 external 5.25\
Graphics card	-
Keyboard type	HP PS/2 Standard Keyboard
Expansion slots	1 PCI, 1 PCI Express Gen1 (x8 mechanically, x4 electrically), 1 PCI Express Gen2 (x8 mechanically, x4 electrically), 2 PCI Express Gen2 (x16 mechanically, x8 electrically), 2 PCI Express Gen2 x16
Pointing device	HP USB Laser Scroll Mouse
Power requirements	1110 watts wide-ranging, active Power Factor Correction, direct connection Power Supplies
Storage drive type	300 GB 15000 rpm SAS 146 GB 15000 rpm SAS SAS 146 GB + 300 GB
HDD controller type	SATA (10000 rpm) SATA (7200 rpm) SAS (15000 rpm)
Video card features	No integrated Graphic Card
Maximum HDD capacity	450 GB
Storage drive controller	Integrated 6 channel SATA 3 Gb/s controller with RAID (0, 1, 5 or 10) capability, integrated 8 channel SAS controller with RAID (0, 1 or 10) capability, optional LSI 8888 ELP 8-port SAS HW with RAID (0, 1, 5 or 10) capability
Minimum storage drive space	146 GB
Operating system installed	Windows Vista Business
Compatible operating systems	HP Installer Kit for Linux
Chassis type	Mini Tower
Country of origin	China

Weight and Dimensions

Depth	526.5 mm
Width	203.5 mm
Height	445.1 mm
Weight	19500 g
