HP Z820 User Manual

Page 4 of 24 Joe Conforti – Avid Technology – September 14th, 2012
Rev A - Initial Public Release
AVID qualified HBA info
AVID qualified HBA AVID Part Number
Slot
Location Function
Vendor qualified 3
rd
party
hardware interface requiring:
x4 PCI-E or lesser interface
¾ Length PCI form factor or
smaller
Not stocked by AVID #1
Vendor qualified 3
rd
party hardware interface. See
release notes and Avid website for information
regarding supported 3
rd
party hardware
Vendor qualified 3
rd
party
hardware interface requiring:
x8 PCI-E or greater interface
Full Length PCI form factor
Not stocked by AVID #6
Vendor qualified 3
rd
party hardware interface. See
release notes and Avid website for information
regarding supported 3
rd
party hardware
Intel PRO 1000 PT 7030-20139-01 #3 Shared Storage: Unity ISIS Copper Gb-Ethernet
Dual Gb ISIS Connectivity
Intel i350-T2 – Dual Gb NIC Not stocked by AVID #3 Shared Storage: Unity ISIS Copper Gb-Ethernet
Dual Gb ISIS Connectivity
Intel PRO 1000 PF - ISIS Not stocked by AVID #3 Shared Storage: Unity ISIS Optical Gb-Ethernet
Myricom 10G-PCIE-8B-S
7030-30041-01 #3 Shared Storage: Unity ISIS 10Gb-Ethernet for
Hi-Res client (ISIS 5000 / 7000)
Avid HIB, DX Interface HBA
**
Active: 7030-30048-01
Active: 7030-20084-01
Passive: 7030-30021-01
#5 Avid DX Hardware Interface HBA
Atto R680 Not stocked by AVID #1 or #4
Local SAS Storage Support –
Avid VideoRAID ST (5-bay)
Xtore StudioRAID 5Ti (5-bay)
LSI 9200-8e SAS controller 7030-30036-01 #1 or #4
SAS Local Storage:
Xtore StudioRAID 16Re (16-bay) chassis
Xtore StudioRAID 5Te (5-bay) chassis
Pro Tools HD h/w
#3 and / or #4
Pro-Tools h/w for Pro-Tools co-install
Red Rocket Accelerator
Not stocked by AVID #3, #4 or #6
Accelerator for RED files
** Avid DX Interface HBA Support Note: (See reference pictures on page 7 of this guide).
All 3 versions of the DX interface HBA are supported on the Z820 with Media Composer / Symphony 6.x and
NewsCutter 10.x
1) Active DX interface HBA 7030-30048-01
2) Active DX interface HBA 7030-20084-01
3) Passive DX interface HBA 7030-30021-01

HP Z820 Specifications

General

Chipset	Intel C602
Processor	Intel Xeon E5-2600 series processors
Memory	Up to 512GB DDR3
Memory Slots	16 DIMM slots
Storage	Supports SATA/SAS/SSD drives
Storage Controllers	optional SAS controllers
Graphics	NVIDIA or AMD professional graphics cards
Drive Bays	4 x 3.5" internal, 3 x 5.25" external
Audio	Integrated HD Realtek ALC262 Audio
Networking	Integrated Intel 82579LM Gigabit Ethernet
Power Supply	1125W
Operating System	Windows and Linux
Dimensions	44.5 x 20.3 x 52.5 cm (17.5 x 8.0 x 20.7 in)
