Page 5 of 24 Joe Conforti – Avid Technology – September 14th, 2012
Rev A - Initial Public Release
4.) Slot Configuration:
Slot Configuration Information
Slot #
Electrical
Mechanical
1
x4 PCI-E Gen 3
x8
Open-
ended
Connector
Vendor Qualified 3
rd
Party Hardware PCI-e Interface requiring:
x4 PCI-E or lesser interface
¾ Length PCI form factor or smaller
OR
(Secondary slot location) Local SAS Storagec ontrollers:
Atto R680
LSI 9200-8e
2
x16 PCI-E Gen 3
(225Watts)
x16
Graphics Card:
Nvidia Quadro 4000
3
x8 PCI-E Gen 3
x16
Shared Storage Controllers ISIS 5000 / 7000:
Intel PRO 1000 PT
Intel PRO 1000 PF
Intel i350-T2
Myricom
10G-PCIE-8B-S
or Pro Tools HD h/w or Red Rocket Accelerator
4
x16 PCI-E Gen 3
x16
Local SAS Storage Controllers:
Atto R680
LSI 9200-8e
or Pro Tools HD h/w or Red Rocket Accelerator
5
x4 PCI-E Gen 2
x16
Avid HIB, DX Interface HBA
Active: 7030-30048-01 & 7030-20084-01
Passive: 7030-30021-01
6
x16 PCI-E Gen 3
x16
Vendor Qualified 3
rd
Party Hardware PCI-e Interface requiring:
x8 PCI-E or greater interface
Full - Length PCI form factor
or Red Rocket Accelerator
7
PCI-E 32bit /33MHz
PCI 32/33
Secondary SAS Port Break-out connector (Embedded)
Embedded Intel
82574L Gb NIC
PCI-E x1
Gen 1
Qualified for Avid ISIS 5000 / 7000 connectivity.
This is the NIC port adjacent to the Firewire port
Embedded Intel
82579LM Gb NIC
PCI-E x1
Gen 1
Do not use for ISIS. Not qualified and is not functional with ISIS 5000 / 7000.
This is the NIC port adjacent to the blue and green audio jacks
