Chapter 10 Parameter Shenzhen Hpmont Technology Co., Ltd.
- 86 - HD09-S Series User Manual V1.1
Ref. Code Function Setting Range Default Unit
Attribute
Setting
d00.11
Master setting frequency
source
0: Keypad set
1: Terninal set
2: Communicaiton set
3: Analogue set
4: Terminal pulse set
6: AI1 terminal setting
10: Keyapd potentiometer setting
11: PID
12: Multi-speed
Actual *
d00.12 Master setting frequency Actual *
d00.13 Auxiliary setting frequency Actual *
d00.14 Setting frequency Actual *
d00.15
Reference frequency (after
Acc. / Dec.)
Actual *
d00.16 Output frequency Actual *
d00.17 Setting RPM Actual *
d00.18 Running RPM Actual *
d00.20 Output voltage Actual *
d00.21 Output current Actual *
d00.22 Torque setting Actual *
d00.23 Output torque Actual *
d00.24 Output power Actual *
d00.25 DC bus voltage Actual *
d00.26
Potentiometer input
voltage of the keypad
Actual *
d00.27 AI input Actual *
d00.28 AI input (after disposal) Actual *
d00.35
DI4 terminal pulse input
frequency
Actual *
d00.36 AO output Actual *
d00.38
High-speed output pulse
frequency
Actual *
d00.39 Heatsink temperature Actual *
d00.40 Setting line speed Actual *
d00.41 Reference line speed Actual *
d00.44 Process PID reference Actual *
