HR Smith Techtest 503-35-1 - Page 15

Commercial In Condence
Issue 17 - 11.04.18 - CN 10407
HRS1013-04-02
13
Figure 5
REMOTE CONTROLLER
503-52
9 way ‘D’ type connector
tted with screwlocks
DZUS Fasteners
ON/Test/Reset
Switch
System Function
Indicator Lamp
Figure 4
REMOTE CONTROLLER
503-4, 503-17, 503-20 & 503-53
DZUS Fasteners
9 way ‘D’ type connector
tted with screwlocks
ON/Test/Reset
Switch
System Function
Indicator Lamp
