HR Smith Techtest 503 Series - Page 14

Commercial In Condence
Issue 17 - 11.04.18 - CN 10407
HRS1013-04-02
Figure 2
G-SWITCH
503-7 & 503-19
26 way ‘D’ type
Connection to
503-1 Transmitter
Figure 3
G-SWITCH with GPS
503-35 & 503-36
26 way ‘D’ type
Connection to
503-1 Transmitter
GPS
ARM/OFF/ON
Toggle Switch
TEST/RESET
Switch
ARM/OFF/ON
Toggle Switch
TEST/RESET
Switch
12
