Connect the Transmitter to a TV with a 3.5mm Audio-out Port
How to Connect the Transmitter to TV
- 5 -
Connect the power adapter to the
transmitter and plug the mains charger
into a power source.
Connect one end of the 3.5mm
audio cable to the audio input port
of the transmitter and the other end
to your TV's audio output port.
The signal indicator on the transmitter
turns red.
Turn on the headphones.
