isolation on the ACs or aggregation switches. When using MSTP to prevent loops, ensure that
the blocked port is one of ports between the ACs and upstream aggregation switches (the four
ports marked red in Figure 1-5).
Figure 1-5 Loop formed when AP management VLAN is the same as a VLAN of switches or
STAs
AC2
AC1
Aggregation switch
Aggregation switch
