4
If the appearance of the product in this document differs from the actual product, the actual
product prevails.
Installing the GPON&XG-PON Terminal
1. Do not install PON terminals outdoors or on the outdoor cabinets.
2. PON terminals can be mounted onto a wall or be placed on a workbench. Do not install
PON terminals in other modes, such as the ceiling.
3. The terminal cannot be connected to other devices such as GPON terminals, switch
and router.
4. After the PON terminal is installed with a support, do not remove the support unless it is
necessary. When you remove the support, apply force evenly on the two sides of the
support to avoid damages to the PON terminal.
Mounting a GPON terminal on the desk
The figure blow shows the ONT that is horizontally placed on a desk.
Mounting terminal vertically on the desk
(Only supported by some product models)
For ONTs with a base: Places the ONT vertically on the desk.
For ONTs with a support: Installs the support to the ONT according to the following figure, and
place the ONT vertically on the desk.
