Huawei eSpace 6870 - Page 3

3
eSpace 6870 Back Panel
(1) Extension board
interface
(2) PC interface
(3) LAN interface
(4) Power interface
(5) RJ-9 earphone interface
(6) Handset interface
Cable Connection for the eSpace 6870
You can install the eSpace 6870 according to the following steps. It is recommended
that you use the original components of the eSpace 6870.
