Step 2 Use a network cable to connect the LAN port to a PC or the Ethernet port on
the IP STB.
Step 3 Use a phone line to connect the TEL port to a phone or fax machine.
Step 4 Use a power adapter to connect the POWER port to the power socket.
Step 5 Press the ON/OFF power switch.
7
1.The optical connector connected to the
OPTICAL
port is an SC/APC connector, and
the type of the optical connector connected to the optical port in the wall is determined by
practical conditions.
2.To ensure normal use of bers, make sure that the ber bend radius is larger than
30 mm.
The preceding gure connects the power adapter as an example. For details about how to
use the backup battery unit, see the usage guide to the backup battery.
Step 1 Set the IP address of the PC in the same subnet as the management IP address
of the GPON terminal.
Step 2 Enter the management IP address of the GPON terminal in the address bar of
Internet Explorer and press Enter.
The login window is displayed.
Step 3 In the login window, select your preferred language, enter the user name and
password ( printed on the nameplate of the device.), and click Login. After the
password is authenticated, the Web configuration window is displayed.
Logging in to the Web Conguration Window
-
Shipped from different manufacture batches, the nameplates of some devices do not have
the IP address, user name, and password printed. In such a case, log in to the device using
192.168.100.1 (or 192.168.1.1), root (user name), and adminHW (password).
- If you do not perform any operations after logging in to the system for ve minutes, you will
exit the system and the system automatically returns to the login interface.
- The system will be locked if you input incorrect user name and password three consecutive
times. One minute later, it will be unlocked.
- Change the initial password after logging in to the web page.
You can nd the default management IP address on the nameplate of the
device.
