Consisting of a dedicated interface board and accessories, the DVK provides the
following interfaces:

Two Micro USB interfaces, one is used for power supply and the other is used to
communicate.

Three standard RS-232 interfaces: 4-line (UART 1), 8-line/4-line (UART 0) and
2-line (UART 2)

Standard Subscriber Identity Module (SIM) card interface

Micro SIM card interface

Three SMA (Small A Type) antenna connectors

SD card interface

Audio interface
1.4 Components of the DVK
Check the components and their quantities after you obtain the DVK. If any
component is missing or damaged, contact with your DVK supplier. Table 1-3 lists the
components of the DVK.
Table 1-3 Components of the DVK
Number
Item
Quantity (pcs)
Category
1
Mother Board
1
Mandatory
2
Interface Board
1
Mandatory
3
Micro USB cable
2
Mandatory
4
Adapter
2
Mandatory
5
External antenna

698 MHz–960 MHz, 1410
MH–2690MHz;

≥ –1 dBi;

Omnidirectional
See note [1]
Mandatory
[1]
6
D3.5 4P Plug Earphone
1
Mandatory
7
RS-232 serial cable
1
Mandatory
8
Handset
1
Optional (only for
MC509 series and
MU509 series module)
9
Handset cable
1
Optional (only for
MC509 series and
MU509 series module)
