Huawei P9 LITE Quick Start Guide

2
Getting started
Follow the instructions in the following figures to set up your
phone. Do not insert or remove a SIM card while your phone
is on.
Please exercise caution when using the SIM ejector pin to
avoid hurting your fingers or damaging your phone. Store
your pin in a safe place out of the reach of children to
prevent them from swallowing it or injuring themselves by
accident.
Insert the SIM card into the correct card slot to ensure
that it can be recognized by the phone.
58
1DQR6,0
1DQR6,0
PLFUR6'
1DQR6,0

Huawei P9 LITE Specifications

General

Display diagonal	5.2 \
Orientation sensor	-
Audio formats supported	AAC, AMR, AWB, FLAC, MID, MP3, MP4, OGG, WAV
Video formats supported	3GP, MKV, MP4, WEBM
Processor cores	4
Processor family	Hi-Silicon
Processor frequency	2 GHz
Coprocessor frequency	1.7 GHz
Processor lithography	16 nm
Coprocessor architecture	ARM Cortex-A53
RAM capacity	3 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Internal storage capacity	16 GB
Flash type	LED
Front camera type	Single camera
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	8 MP
Battery capacity	3000 mAh
2G standards	GSM
3G standards	UMTS
SIM card type	NanoSIM
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
3G bands supported	900, 1900, 2100 MHz
SIM card capability	Single SIM
2G bands (primary SIM)	850, 900, 1800, 1900 MHz
Mobile network generation	4G
Graphics card	Mali T830
Graphics & IMC lithography	28 nm
USB connector type	Micro-USB
HDMI ports quantity	0
Headphone connectivity	3.5 mm
Form factor	Bar
Product color	White
Platform	Android
Operating system installed	Android 6.0
Storage temperature (T-T)	-20 - 45 °C
Operating temperature (T-T)	0 - 35 °C
Cables included	USB

Weight and Dimensions

Depth	7.5 mm
Width	72.6 mm
Height	146.8 mm
Weight	147 g
