4 Technical Specifications
4.1 Basic Specifications
Table 4-1 Basic specifications of the R230D
Item Description
Technical specifications Dimensions (H x W x D) 26 mm x 120 mm x 86 mm
Weight 0.1 kg
System memory
128 MB DDR2
32 MB flash memory
Power parameters Power input
PoE power supply in
compliance with IEEE
802.3af
Maximum power
consumption
5.1 W
NOTE
The actual maximum power
consumption depends on local
laws and regulations.
Environment specifications Operating temperature and
altitude
-60 m to 1800 m: 0°C to
40°C
1,800 m to 5,000 m: The
highest operating
temperature reduces by 1°C
every time the altitude
increases by 300 m.
Storage temperature -40°C to +70°C
Operating humidity 5% to 95%
(non-condensing)
IP rating IP20
Atmospheric pressure 70 kPa to 106 kPa
