Figure 7-13 Grid parameters
Table 7-5 Grid parameters
Parameter
Description
Grid Code Set this parameter based on the grid code of the country or
region where the inverter is used and the inverter application
scenario.
Isolation settings Set the working mode of the inverter based on the grounding
status at DC side and the connection to the power grid.
Output mode Species whether the inverter output has a neutral wire based
on the application scenario.
Automatically start upon grid
recovery
Species whether to allow the inverter to automatically start
after the power grid recovers.
Grid connected recovery time
from grid faults (s)
Species the time after which the inverter begins restarting
after the power grid recovers.
SUN2000-(75KTL, 100KTL, 110KTL, 125KTL) Series
User Manual 7 Man-Machine Interactions
Issue 11 (2021-11-10) Copyright © Huawei Technologies Co., Ltd. 88
