Overview
Copyright © Huawei Technologies Co., Ltd. 2023.
All rights reserved.
The information in this document is subject to change without notice. Every effort has been made in
the preparation of this document to ensure accuracy of the contents, but all statements,
information, and recommendations in this document do not constitute a warranty of any kind,
express or implied.
Only certified electricians are allowed to operate the device. Operation personnel should understand
the composition and working principles of the grid-tied PV power system and local regulations.
Before installing the device, read the user manual carefully to get familiar with product information
and safety precautions. Device damage caused by failure to abide by the storage, transportation,
installation, and operation guidelines specified in this document and the user manual is not covered
under the product warranty.
Use insulated tools when installing the device. For personal safety, wear proper personal protective
equipment (PPE).
(1)
Panel
(2) LED indicators
(3) Maintenance compartment door
(4) Mounting bracket
(5) External fan tray
Appearance
Port Description
(1) DC input terminal group 1 (PV1
PV8,
controlled by DC SWITCH 1)
(2) DC switch 1 (DC SWITCH 1)
(3) Reset button 1
(RESET 1)
(4) DC input terminal group 2 (PV9
PV14,
controlled by DC SWITCH 2)
