Huba Control 699 - Measurement Configuration: Version with Measurement Configuration Only; Component Identification (DIP-Switch Dual); Pressure Range Selection

5
Huba Control AG - 699/full - Edition 08/2012 - 114507
Version with measurement configuration only
(Adjustability 1)
1)
Pressure range
2)
Customized factory adjustment
3)
DIP-Switch position according to factory adjustment (see inside cover)
1. DIP-Switch (dual)
2. Zero point reset
3. Connecting terminals
4. Pressure connectors
P1 and P2
1
2
3
4
Pressure range
1)
Range00
Range01
Range10
customer adjustment
2)
1
0
3)
