hubs dome - Page 2

Parts checklist
2. To clamp-up the hubs
1. To build the dome
x6
x35
x30
x20
Allen key
Used to hold
the hub screws
in position when
clamping the hubs.
For the base
You will need
another 10 wood
screws or another
20 ball connectors
and 20 wood screws
depending on which
base approach you
go for. These are
included in the kit.
See the Completing
your dome section
for more.
x1
Hanging eyelet
Use this to hang
something nice
from the centre
of your dome.
x26
Hub screw
Goes through the
centre of the
hub for clamping.
x26
Locking plate
Clamps the ball
connectors in place
once the dome is in
its fi nal position.
x25
Wing nut
Screws onto the end
of the hub screw to
clamp the locking
plate in place.
SHORTS
LONGS
