Specs………….………………………………………………………………………………………
Model Number: HC10X-USB2-(xx) Color (xx): BK=Black; WH=White
Camera & Lens
• Video CMOS Sensor 1/2.9” HD Sony CMOS, 2.1 Mega Pixel
• Frame Rate 30fps 1920 x 1080
• Lens Zoom 10X Optical Zoom f=4.7 47mm
• Min Lux 0.1 Lux at F1.6
• Field of View 8° (tele) to 60° (wide)
• Warranty 2 Years
Pan/Tilt Movement
• Pan Movement ±175°
• Tilt Rotation Up: 90°, Down: 30°
• Presets 64 Presets
Rear Board Connectors
• Video Interface USB 2.0, UVC 1.5
• Control Signal Interface UVC 1.5 - Mini DIN-8 (RS232 IN, RS485 IN, Pelco-D/P
IN/OUT)
• Control Signal Config. Dome - On Screen Display Menu
• Baud Rate 9600 bps
• Power Supply Interface DC 12V 2A
Electrical Index
• Power Supply Adapter 12V DC 2A
• Input Voltage 12V DC (10.5-14V DC)
• Input Power 24W (Max)
• Working Environment Indoor
Physical
• Material Aluminum, Plastic
• Dimensions 4.88”W x 5.5”H x 4.75”D (6” H w/ Tilt up)
124mm x 139mm x 120mm (152mm H w/ Tilt up)
• Weight 1.66 lbs (.75 kg)
• Box Dimensions 8.75” x 8.88” x 7” (222mm x 225mm x 178mm)
• Boxed Weight 3.66 lbs | 1.66 kg
• Color Black & White
• Operating Temperature 32°F to + 113°F (0°C to +45°C)
• Storage Temperature -14°F to 140°F (-10°C +60°C)
• Working Environment Indoor only
