Page 3 of 15
Ver 1.2 11/20
2. Rear View………………………………………………………………………………………….
5. DC IN 12V Socket
Only use the Power Adapter supplied with this camera.
6. IR Receiver
To receive IR remote controller signals.
7. RS232 IN Port
For hard wired remote control from a 3
rd
party PC, joystick, etc...
8. RS485 IN Port
For hard wired remote control from a 3
rd
party PC, joystick, etc...
9. USB 2.0 Interface
For connection to PC USB 2.0 port. Will also function in a USB 3.0 port as USB 2.0
device.
