Huffy 214636E - Page 22

22
P/N 214636E 03/04
4.
Attach upper elevator tubes (35) to backboard support brackets (27) using
spacers (26 & 11)), bolt (29), and nut (31) as shown.
35
35
26
27
26
31
11
29
29
27
26
31
11
Peel protective
film from surface
of acrylic
backboard prior
to use.
NOTE:
