Huffy 540D User Manual

12
ID# 21198805 10/05
Do not use
washers here on
spring return
style rims.
20
19
16
21
15
18
10
29
7.
Install backboard assembly to the pole assembly as shown. Attach backboard and
rim (16) to the extension arm (18) using bolts (20), spacers (21), washers (10, 19) and
nuts (15) as shown. Tighten completely. Attach bolt covers (29).
TWO PEOPLE REQUIRED
FOR THIS PROCEDURE.
FAILURE TO FOLLOW THIS
WARNING COULD RESULT IN
SERIOUS INJURY AND/OR
PROPERTY DAMAGE.
WARNING!
Peel protective
film from surface
of acrylic
backboard prior
to use.
NOTE:
BOARD STYLE
MAY VARY
NOTE:

Huffy 540D Specifications

General

Brand	Huffy
Model	540D
Category	Fitness Equipment
Language	English
