Huffy 540D - Section A: Assemble the Base; Tools Required for Base Assembly; Hardware Used in Base Assembly

10/05 ID# 21198805
7
TOOLS REQUIRED FOR THIS SECTION
HARDWARE USED IN THIS SECTION
(not actual size)
SECTION A: ASSEMBLE THE BASE
9/16” and 1/2”
9/16” and 1/2”
AND/OR
This is what your system will look
like when you’ve finished this
section:
Item #12
Item #10
Item #8
Item #14
Item #15
Item #19
Item #26
Item #6
Item #9
Item #5
* Units with 42” steel frame acrylic
backboard do not require the use of
included board struts (.75” x 22”)
NOTE:
