Huffy Backboard and Rim User Manual

6
P/N 211540D 06/03
Item Qty. Part No. Description
1 4 202341 “L” Bracket
2 2 200837 Spacer, Plastic
3 6 201107 Bolt, Hex Head, 1/4-20 x 1/2 Long
4 6 203326 Washer, Lock, 1/4
5 6 203228 Nut, 1/4-20
6 8 203100 Hex Flange Nut 5/16-18
7 4 203104 Bolt, Hex Flange, 5/16-18 x 2 Long
8 2 900964 Bracket, Backboard Support
9 2 206360 Bolt, Hex Head, 3/8-16 x 2.625 Long
10 2 200874 Spacer, Steel .402 I.D. x .50 O.D. x 1.5 Long
11 2 201124 Nut, 3/8-16
Item Qty. Part No. Description
12 1 Rim
13 12 201219 Clip, Net Holder, Smart Clips
14 1 Net
15 4 205528 Bolt, Hex Flange, 5/16-18 x 1 Long
16 8 203309 Washer, Flat
17 4 202862 Spacer, Plastic,1.19" Long
18 2 201640 Bolt, Hex, 1/2-13 X 7.25 Long
19 2 206340 Lock Nut, Nylon Insert, 1/2-13
Item #13 (12*)
Item #3 (6)
Item #5 (6)
Item #6 (8)
Item #11 (2)
Item #15 (4)
Item #16 (8)
Item #4 (6)
Item #10 (2)
Item #7 (4)
Item #9 (2)
HARDWARE IDENTIFIER (BOLTS)
HARDWARE IDENTIFIER (NUTS & WASHERS)
HARDWARE IDENTIFIER (STEEL SPACERS)
HARDWARE IDENTIFIER (PLASTIC SPACERS & CLIPS)
PARTS LIST (See Hardware Identifiers)
Item #18 (2)
Item #19 (2)
Item #17 (4)
