12
P/N 214969B 05/03
31.
WARNING:
Use of this product without proper installation of net
clips, or when all net clips are not present could result in bodily harm. Be sure
to follow directions carefully.
Install net clips.
CLIP “ARM”
CLIP “BODY”
Insert one “arm” of clip into ram as shown. Twist “body” of clip slightly so that
second “arm” slides over the top of the first “arm” as shown.
Push in direction indicated by arrows.
Push second “arm” back and into ram as shown.
Twist “body” of clip slightly again to spread “arms” of clip.
Clip “arms” must be flat and touching edge to edge as shown, not overlapping.
AA
BB
CC
40
41
To Next Page
