4
P/N 214969B 05/03
PARTS LIST
(See Hardware Identifier)
Item
Qty.Part No. Description
1 1 914822 Top Pole Section
2 1 908407 Middle Pole Section
3 1 908812 Bottom Pole Section
4 1 202800 Ground Sleeve
5 1 202801 Ground Sleeve Cap
6 1 203279 Anti-Skid Tape
7 1 204839 Tinnerman Nut
8 1 904816 Inside Channel
9 1 904815 Outside Channel
10 1 204813 Handle
11 2 203217 Carriage Bolt, 5/16-18 x 1-1/2 Long
12 5 203218 Washer, 5/16, 3/8 ID, 7/8 O.D.
13 11 203100 Nut, Hex Flange, 5/16-18
14 1 203679 Bolt, Hex Head, 3/8-16 x 2 Long
15 2 201124 Lock Nut, Hex 3/8-16
16 1 204814 Trigger
17 1 203589 Bolt, Hex Head, 5/16-18 x 1-1/4 Long
18 1 201125 Spring
19 1 204809 Label, Height Indicator
20 4 201611 Bolt, Hex Flange, 5/16-18 x 3 Long
21 2 204840 Pin, 3 x 3/8
22 2 204841 Looped Springs
23 1 204819 Pole Mount Bracket, Zinc
24 2 203053 Carriage Bolt, 5/16-18 x 4 Long
25 1 204811 Spring Cover, Left
26 1 204812 Spring Cover, Right
27 1 206263 Carriage Bolt, 5/16-18 x 3 Long
28 4 201129 Spacer, 1.8 long x .402 I.D. x .5 O.D.
29 2 900846 Backboard Bracket
30 1 240017 Bolt, Hex Head, 1/4-20 x 2-1/4 Long
31 1 206990 Reinforcement Bracket
32 1 203493 Nut, Hex Head, 1/4-20, Center-lock
33 2 904807 Upper Elevator Tube (Black)-Short
34 2 904821 Lower Elevator Tube (Black)-Long
35 6 204847 Bolt, Hex Head, 1/2-13 x 9-1/2 Long
36 6 206340 Lock Nut, Hex Center-lock, 1/2-13
37 12 202862 Spacer, Plastic, 1/2 I.D., 1-1/4 Long
38 2 204838 Spring
39 2 206311 Spacer, Plastic, 1/2 I.D., 1/2 Long
40 1 Rim
41 12 201219 Smart Clip, Net Holder
42 2 203108 Carriage Bolt, 5/16 x 2-1/2 Long
43 1 202789 Bolt, Hex Head, 3/8-16 x 6 Long
44 1 Net
45 1 201247 Label, Height Adjustment
46 1 207103 Pole Cap
47 2 203309 Washer, 1 O.D.
* YOU MAY HAVE EXTRA PARTS WITH THIS MODEL
.
WARRANTY CARD:
Please remember to complete your product
registration form either
on-line at: www.huffysports.com/warrantycard
or mail-in the enclosed postcard.
