Schlafen: GENTISE 1. 2021
Notes on delivery:
Gentis low-, side- and highboards consist of several component groups which are delivered
separately and have to be assembled on site.
These component groups are the cover shelf, the side end units and the main carcase (for 2
and 3 Raster low- and sideboards up to and including 211.2 cm width, as well as for 4 Raster
low- and sideboards up to and including 176.0 cm width) resp. the main carcases (for low- and
sideboards that are wider than those mentioned above).
The fronts of the individual component groups are already fitted but can be disassembled on site.
Glass versions:
Outer glass sides of (wall) cabinets, glass shelves behind fronts as well as bookshelves and
glass accents of wall shelf unit of bronzed glass.
Cabinet compartment rear wall and rear wall of wall shelf unit also possible in all versions
(exception: leather versions).
Accent units:
Carcase and front also in the versions knotted oak, knotted oak anthracite, knotted core walnut,
Nappa leather and Nubuk-Touch leather possible (exception: accent unit of hinge-doors cloakroom
units is not available in leather versions).
Interior carcase:
The interior carcase of the versions pure white lacquer, white lacquer, high-gloss pure white
lacquer and high-gloss white lacquer is in a matt white lacquer version. The same applies to the
straight outer side of the lowboards with rounded end at one side. The interior carcase of the
versions grey lacquer, silk grey lacquer, high-gloss grey lacquer and high-gloss silk grey lacquer
as well as of the accent units in leather version is in a matt grey lacquer version. The same applies
to the straight outer side of the lowboards with rounded end at one side.
Open section of the hinge-doors cloakroom units:
The open section of the hinge-doors cloakroom units of the high-gloss lacquer versions is in a
matching matt lacquer colour.
Hinge-doors for end units:
The sideward distance must be 27 cm (per door) to open doors fully.
Standard interior fittings:
Fitted wooden shelves are fitted behind doors at intervals of 2 Raster (exception: 12 Raster
cabinets).
Functional frame:
Functional frame always in white lacquer.
Wall units:
If units are planned as wall units, a wall bracket must be ordered.
Drawer frames in standard grey.
Combinations of floor and wall units:
If floor and wall units are combined within an arrangement, there must not be any skirting boards
in the room near the floor units, otherwise they must be removed.
Max. load:
Maximum load of wooden and glass shelves (up to 70.4 cm width) as well as drawers: 25 kg
Maximum load of wooden and glass shelves (between 70.4 and 105.6 cm width): 15 kg;
from 105.6 cm width: 10 kg
Maximum load of cover shelves: 35 kg per metre length for floor units.
Please also note any other data on maximum loads for individual units on the pages inside!
hülsta-Push-to-open:
Drawers and flap units with hülsta Push-to-open. All drawers on hidden roller bearings as fully
pull-out units.
Important notes: Generally speaking, you as a dealer/qualified fitter are responsible for the correct wall mounting of the units.
That is why wall mounting should only be carried out by properly trained and qualified fitters. hülsta supplies materials for
mounting units on walls for nearly all the units and which should be used for safety and for constructional reasons. The assembly
materials supplied by hülsta (plugs, screws) are only suitable for fitting components on to concrete in firmness class C12/15.
For other materials (please see separate materials table in the wall composition chapter) we provide you with an assembly mortar
set as an extra order. Please note that this assembly mortar set is also only suitable for the materials listed in the materials table.
If walls are made up of other materials (e.g. plastered or lighter wall materials), one should use another method of mounting better
suited to the load on site. Please note that if the units are not mounted properly on the wall, there is a risk of the units falling down
or tipping over – especially when alternative mounting materials acquired on site have been used.
For the reasons stated above it is absolutely essential to enquire about the composition of any walls before signing any contracts.
Wall fitting
3
4
Labelling in type list drawings /
assembly notes for wall units
Notes on delivery
Labelling in type list drawings /
assembly notes for wall units
The majority of units have two wall mounting points (= number of base plates),
if these are to be fitted as wall units. This is not explicitly mentioned in the type
list. If a dierent number of wall mounting points (= base plates) is required,
this is marked in the drawings in the type list with numbers in black boxes.
Please be sure to note here the information and notes in the “Wall composition”
chapter!
Range introduction
Important notes
