Human Touch HT-120 - Page 2

3. Pull gently outward on the bottom of one of the side panels to remove it (Fig.4).
4. Use a needle-nosed pliers to remove the cotter pin from the side panel, then use a vice grip to pry the hinge pin loose from the side panel and remove it (Fig.5).
NOTE: When the hinge pin is removed, the two spacers that are located between the backrest and the chair base will most likely fall off Fig.6). Be sure to set
these spacers aside for use during reassembly.
5. Repeat steps 6 and 7 on the other side panel.
6. Carefully lift the backrest up and off the chair base.
Cotter pin
Hinge pin
(Fig.5)
Backrest
spacers
(Fig.6)
2
(Fig.4)
