8. Repeat steps 2 - 7 on the other side panel.
9. Reconnect the cables at the connector box on the bottom right-hand side of the chair (Fig.9).
10. Using a Phillips-head screwdriver, secure the connector box cover using the two screws you removed earlier.
11. Reconnect the cables at the connector box on the bottom left-hand side of the chair (Fig.10).
12. Using your fingers, secure the connector box cover.
13. Replace the zip ties you removed previously, to secure the connector boxes and cables to the bottom of the chair.
14. Reinstall the chair pads (See the Use & Care manual for instructions).
15. Plug in and power on the chair, then verify that both the massage and recline functions work.
(Fig.9) (Fig.10)
4
Please send any questions or comments regarding these instructions to: documentation@humantouch.com
© 2010 Human Touch
™
, LLC.
Connector box
(Right-hand side of the chair)
Cables
Connector box
(Left-hand side of the chair)
Cables
