Replacement of the iJoy 100 Remote with Cable
PCB
Module
Remote Cord
AC Cord
Access to Screws
* Screw on right may be under product information label
Side Panel Detail
Four screws securing
Cable Clamp to Cover
Remote Control
Cable Connecto
r
*
Slide out clamp to remove
Controller and Cable
AC Cable
Connecto
r
Ground
W
ire
