General information
Product description
2
Tandem wheels-in trailer as multi-transporter in the building trade
Fig. 1 Example HBT - front view
1 Tube drawbar with towing eye
2 24 V electrical connections
3 Compressed-air connections: supply,
brake
4 Geared support winch
5 Screw parking brake (up to 13 t)
6 Height adjustment, vertical
7 Swivel support (option)
8 Height adjustment, horizontal
9 Front wall, slot-in
10 Rear platform gate
The construction machine transporters
HBT BE / HBT BS / HBTZ BS differ in the
type of loading aids such as different
ramp planks / drive-up ramps and the
different payload.
The coupling height to the towing vehicle
can be infinitely varied with the standard
tube drawbar height adjustment.
The geared support winch ensures that
the trailer can be easily set down on off-
road terrain. The trailer can be secured
against rolling away with the screw
parking brake.
1
3
4
5
6
8
9
2
7
10
