Electrical system
245
Tail light with peripheral light
1
2
3
4
5
6
7
8
LED tail light with peripheral light
The rear LED tail lights are equipped with
the following functions:
– Fog and reversing lights
– Tail light with reflector, brake light and
indicator
– Peripheral light
WARNING
Non-functioning tail lights
The road users cannot correctly gauge/
identify the vehicle - risk of injury!
Check that the tail and peripheral
lights are secured before departing.
Fig. 21 “LED” tail lighting
1 Light source with:
fog/reversing light
2 Light body with:
Tail light with reflector, brake light and
indicator
3 Peripheral light
3
1
2
