Hydraulic supply
88 Operation: chassis
4
Fig. 29 Label on trailer
1 Max. oil pressure (Pmax.): 180 bar
2 Max. oil quantity: 10 l
3 Operating temperature: -30 °C / + 100 °C
Fig. 30 Hydraulic lines
for towing vehicle
1 “PRESSURE” hydraulic line
2 “RETURN” hydraulic line
3 Line connection (SVK BG3)
Teleskop-Zylinder / Hydraulik
+
-
620.00524
Max. Nennlast (Zuladung)
Rated load = 16.000 kg
(= max. 200 bar)
= 17,0 l (dm³)
= -30 ... + 100 °C
F - 082
1
2
3
