Hummer 2005 H2 User Manual

Fuses Usage
DRIVER UNLOCK
Power Door Lock
Relay (Driver’s Door
Unlock Function)
IGN 0
Brake Transmission Shift
Interlock, Powertrain Control
Module, Transmission
TBC IGN 0 Truck Body Controller
VEH CHMSL
Vehicle and Trailer High
Mounted Stoplamp
LT TRLR ST/TRN Left Turn Signal/Stop Trailer
LT TRN
Left Turn Signals and
Sidemarkers
VEH STOP
Vehicle Stoplamps, Brake
Module, Electronic Throttle
Control Module
RT TRLR ST/TRN Right Turn Signal/Stop Trailer
RT TRN
Right Turn Signals and
Sidemarkers
Fuses Usage
BODY Harness Connector
DDM Driver Door Module
LOCKS
Rear Doors and Liftgate
Power Lock Relay Feed
ECC Liftgate
TBC 2C Truck Body Controller
FLASH Flasher Module
CB LT DOORS
Left Rear Power Window
Circuit Breaker and Driver
Door Module
TBC 2B Truck Body Controller
TBC 2A Truck Body Controller
Circuit Breaker Usage
AUX PWR 2 Midgate Controller (SUT Only)
5-105
